Driver Convenience

Driving Assistant Plus Preparation

Stop/start button

Entertainment

DAB tuner

Exterior Body Features

Body colour door handles

Body coloured bumpers

M high gloss shadow line with extended contents - Radiator grille frame, struts and strip in rear light

Rear boot

Rear side wing doors

Interior Features

3 spoke leather M steering wheel in BMW M specific design with M badge

Armrest - front and rear integrated door trim, centre console includes storage compartment, rear centre includes 2 cupholders

High-gloss black door switch cluster, power window switch and tailgate button on first and second row seat

M Anthracite headlining

M Sport pedal covers in stainless steel

Wireless charging tray

Packs

Ambient lighting pack - 5 Series/I5

BMW Iconic glow kidney grille exterior package

Connected package professional - 5 Series/I5

Driving assistance pack - 5 Series/I5

Expanded exterior mirror package - 5 series/I5

M high gloss shadow line pack - 5 Series/ I5

M Sport exterior styling pack - 5 Series/I5

Safety

3 rear three point seatbelts

Active protection

Airbag deployment is controlled with respect to the intensity and scope

Crash sensor activating central locking release, hazard warning lights, fuel cut off and interior lighting

Driver and front passenger airbags

Driver central airbag

Driver/front passenger side airbags

Front and rear curtain airbags

Front head restraints with anti-whiplash

Head airbags for first and second row seats

Locking of doors after driving off

M seat belts

Mechanical child proof lock on rear doors

Side impact protection

Two tone horn

Tyre pressure monitoring system

Warning triangle and first aid kit

Security

Alarm system

Locking wheel bolts including wheel bolt adapter

Electric Vehicle Data

Battery Capacity in kWh	22.1
Battery Charging Scenario 1 - Charge Time (Mins)	705
Battery Charging Scenario 1 - Percentage Change	0-100
Battery Charging Scenario 1 - Power Supply - kW	2.3
Battery Charging Scenario 2 - Charge Time (Mins)	195
Battery Charging Scenario 2 - Percentage Change	0-100
Battery Charging Scenario 2 - Power Supply - kW	7.4
Battery Charging Scenario 3 - Charge Time (Mins)	135
Battery Charging Scenario 3 - Percentage Change	0-100
Battery Charging Scenario 3 - Power Supply - kW	11
Battery Leased	False
Battery Type	Lithium-ion
Charging Port Location	Left Side Front
Coupler/Connector Type	Type 2
Maximum Charging Rate - kW	11
Standard manufacturers Battery warranty - Mileage	100000
Standard manufacturers Battery warranty - Years	8
Usable Battery Capacity	19.4
WLTP - AER (km) - City	110
WLTP - AER (km) - Comb	99
WLTP - AER (miles) - City	68.4
WLTP - AER (miles) - Comb	61.5
WLTP - EC (kWh/100km) - City	18.8
WLTP - EC (kWh/100km) - Comb	20.7
WLTP - EC (kWh/100km) - Extra High	24.9
WLTP - EC (kWh/100km) - High	17.8
WLTP - EC (kWh/100km) - Low	20
WLTP - EC (kWh/100km) - Medium	18.3
WLTP - EC (miles/kWh) - City	3.3
WLTP - EC (miles/kWh) - Comb	3
WLTP - EC (miles/kWh) - Extra High	2.5
WLTP - EC (miles/kWh) - High	3.5
WLTP - EC (miles/kWh) - Low	3.1
WLTP - EC (miles/kWh) - Medium	3.4
WLTP - EC AC Ch Dep (kWh/100km) - Comb	21.4
WLTP - EC AC Ch Dep (miles/kWh) - Comb	2.9
WLTP - EC AC Weighted (kWh/100km) - Comb	20
WLTP - EC AC Weighted (kWh/100km) - Comb - TEH	21.2
WLTP - EC AC Weighted (kWh/100km) - Comb - TEL	19.8
WLTP - EC AC Weighted (miles/kWh) - Comb	3.1
WLTP - EC AC Weighted (miles/kWh) - Comb - TEH	2.9
WLTP - EC AC Weighted (miles/kWh) - Comb - TEL	3.1
WLTP - Equivalent AER (km) - City	109
WLTP - Equivalent AER (km) - Comb	100
WLTP - Equivalent AER (km) - Comb - TEH	95
WLTP - Equivalent AER (km) - Comb - TEL	103
WLTP - Equivalent AER (km) - Extra High	83
WLTP - Equivalent AER (km) - High	114
WLTP - Equivalent AER (km) - Low	103
WLTP - Equivalent AER (km) - Medium	113
WLTP - Equivalent AER (miles) - City	67.7
WLTP - Equivalent AER (miles) - Comb	62.1
WLTP - Equivalent AER (miles) - Comb - TEH	59
WLTP - Equivalent AER (miles) - Comb - TEL	64
WLTP - Equivalent AER (miles) - Extra High	51.6
WLTP - Equivalent AER (miles) - High	70.8
WLTP - Equivalent AER (miles) - Low	64
WLTP - Equivalent AER (miles) - Medium	70.2

Emissions - ICE

CO	0.202
HC	0.015
NOx	0.014
Particles	0.0002
Standard Euro Emissions	EURO 6

Emissions - Lifecycle

End-of-Life Emissions - CO2e (Equivalent) - tonnes	0.6
In-Life Emissions - CO2e (Equivalent) - tonnes	11.1
Lifetime Emissions - CO2e (Equivalent) - tonnes	26.3
Production Emissions - CO2e (Equivalent) - tonnes	14.6

Emissions - PHEV

WLTP - CO2 Ch Sus (g/km) - Comb	153
WLTP - CO2 Ch Sus (g/km) - Extra High	153
WLTP - CO2 Ch Sus (g/km) - High	136
WLTP - CO2 Ch Sus (g/km) - Low	216
WLTP - CO2 Ch Sus (g/km) - Medium	138
WLTP - CO2 Charge Depleting (g/km) - Comb	7
WLTP - CO2 Weighted (g/km) - Comb	15
WLTP - CO2 Weighted (g/km) - Comb - TEH	17
WLTP - CO2 Weighted (g/km) - Comb - TEL	14

Engine and Drive Train

Camshaft	DOHC
Catalytic Convertor	True
CC	1998
Compression Ratio	11.6:1
Cylinder Layout	IN-LINE
Cylinders	4
Cylinders - Bore (mm)	82
Cylinders - Stroke (mm)	94.6
Engine Code	XB1141M2
Engine Layout	NORTH SOUTH
Fuel Delivery	TURBO INJECTION
Gears	8 SPEED
Number of Valves	16
Transmission	SEMI-AUTO

Fuel Consumption - ICE

EC Directive 1999/100/EC Applies	False

Fuel Consumption - PHEV

WLTP - FC Ch Dep (l/100km) - Comb	0.2
WLTP - FC Ch Dep (mpg) - Comb	1412.4
WLTP - FC Ch Sus (l/100km) - Comb	6.8
WLTP - FC Ch Sus (l/100km) - Extra High	6.8
WLTP - FC Ch Sus (l/100km) - High	6
WLTP - FC Ch Sus (l/100km) - Low	9.6
WLTP - FC Ch Sus (l/100km) - Medium	6.1
WLTP - FC Ch Sus (mpg) - Comb	41.5
WLTP - FC Ch Sus (mpg) - Extra High	41.5
WLTP - FC Ch Sus (mpg) - High	47.1
WLTP - FC Ch Sus (mpg) - Low	29.4
WLTP - FC Ch Sus (mpg) - Medium	46.3
WLTP - FC Weighted (l/100km) - Comb	0.7
WLTP - FC Weighted (l/100km) - Comb - TEH	0.8
WLTP - FC Weighted (l/100km) - Comb - TEL	0.6
WLTP - FC Weighted (mpg) - Comb	403.5
WLTP - FC Weighted (mpg) - Comb - TEH	353.1
WLTP - FC Weighted (mpg) - Comb - TEL	470.8

General

AdBlue	False
Alternative Fuel Qualifying	True
Badge Engine CC	2.0
Badge Power	299
Coin Description	e
Coin Series	M Sport Pro [Comf+]
Generation Mark	8
Insurance Group 1 - 50 Effective January 07	40E
NCAP Adult Occupant Protection %	89
NCAP Pedestrian Protection %	86
NCAP Safety Assist %	78
Safety Concerns	False
Special Edition	False
Special Order	False
Vehicle Homologation Class	M1

Performance

0 to 62 mph (secs)	6.3
Engine Power - BHP	299
Engine Power - KW	220
Engine Power - PS	True
Engine Power - RPM	5000
Engine Torque - LBS.FT	332
Engine Torque - MKG	45.9
Engine Torque - NM	450
Engine Torque - RPM	1500
Top Speed	143

Test Cycles

Emissions Test Cycle	WLTP
RDE Certification Level	RDE 2

Tyres

Alloys	True
Space Saver	False
Tyre Size Front	245/40 R20
Tyre Size Rear	275/35 R20
Tyre Size Spare	TYRE REPAIR KIT
Wheel Style	STAR SPOKE STYLE 938 M
Wheel Type	20" ALLOY

Vehicle Dimensions

Height	1515
Length	5060
Wheelbase	2995
Width	1900
Width (including mirrors)	2156

Weight and Capacities

Fuel Tank Capacity (Litres)	60
Gross Vehicle Weight	2655
Luggage Capacity (Seats Up)	520
Max. Loading Weight	650
Max. Roof Load	75
Max. Towing Weight - Braked	1800
Max. Towing Weight - Unbraked	750
Minimum Kerbweight	2005
No. of Seats	5
Turning Circle - Kerb to Kerb	11.7
