Driver Convenience

Emergency services call system

Hands free power tailgate

Entertainment

DAB Digital radio

Low speed exterior sound speaker

Premium Sound by Harman Kardon, Dolby Pro Logic II Surround Sound, Dirac Unsion,12 speakers/600W and subwoofer

Steering wheel remote infotainment controls

Exterior Body Features

Black stone boot spoiler

Black stone roof

Body colour pillars

Body colour roof spoiler

Colour co-ordinated front grille and surround

Fixed panoramic glass sunroof

Front recharge tread plates

High gloss black rear bumper lower deco

High gloss black window trim

Rear side wing doors

Roof antenna

Visible VIN plate

Interior Features

12V socket in front tunnel console

3 spoke sports tailored steering wheel

A-pillar parking ticket holder

Bright metal luggage compartment threshold

Centre console cupholders and storage

Charcoal headlining

Charcoal lower dashboard, upper tunnel console and armrest

Flexible load floor and grocery bag holder

Front door pocket and front cupholder illumination

Front load compartment (31 litres)

Front tunnel net pocket and integrated waste bin

Glovebox bag hook

Height/reach adjustable steering column

High gloss black centre tunnel and centre screen surround deco

Load protection net

One pedal drive mode

Rear armrest with cupholder

Underfloor cargo storage

Packs

Climate pack - C40/XC40

Safety

3x3 point rear seatbelts

City safety includes pedestrain and cyclist detection, front collision warning with full and rear auto brake

Drivers knee airbag

Dual stage driver/passenger airbags

First aid kit

Front and outer rear seatbelt reminder and pretensioners

Front seats SIPS airbags

IC (Inflatable Curtains) - Full Length

ISOFIX attachment (Front passenger and Rear outer seats)

Passenger airbag cut-off device

Power child locks on rear doors

Road sign information display

Run off Road Mitigation

Run off Road Protection

SIPS (Side Impact Protection System)

Slippery road and hazard light alert

Tyre pressure monitoring system

Warning triangle

WHIPS whiplash protection system - front

Security

2 x Key integrated remote control central locking including recharging port with deadlocking system and auto open/close power windows and sunroof

Anti-theft alarm including immobiliser/volume sensor + level sensor

Care key with user defined top speed

Convenient entry and start

Keyless drive with keyless entry and keyless start

Locking wheel nuts

Private locking for tailgate

Electric Vehicle Data

Battery Capacity in kWh	69
Battery Charging Scenario 1 - Charge Time (Mins)	2100
Battery Charging Scenario 1 - Percentage Change	0-100
Battery Charging Scenario 1 - Power Supply - kW	2.3
Battery Charging Scenario 2 - Charge Time (Mins)	1260
Battery Charging Scenario 2 - Percentage Change	0-100
Battery Charging Scenario 2 - Power Supply - kW	3.7
Battery Charging Scenario 3 - Charge Time (Mins)	660
Battery Charging Scenario 3 - Percentage Change	0-100
Battery Charging Scenario 3 - Power Supply - kW	7.4
Battery Charging Scenario 4 - Charge Time (Mins)	34
Battery Charging Scenario 4 - Percentage Change	10-80
Battery Charging Scenario 4 - Power Supply - kW	130
Battery Leased	False
Battery Type	Lithium-ion
Charging Port Location	Left Side Rear
Coupler/Connector Type	CCS Type 2
Maximum Charging Rate - kW	130
Standard manufacturers Battery warranty - Mileage	100000
Standard manufacturers Battery warranty - Years	8
Usable Battery Capacity	66
WLTP - EC (kWh/100km) - Comb - TEH	17.5
WLTP - EC (kWh/100km) - Comb - TEL	16.2
WLTP - EC (miles/kWh) - Comb - TEH	3.6
WLTP - EC (miles/kWh) - Comb - TEL	3.8
WLTP - Pure Electric Range (km) - Comb	476
WLTP - Pure Electric Range (km) - Comb - TEH	445
WLTP - Pure Electric Range (km) - Comb - TEL	486
WLTP - Pure Electric Range (miles) - Comb	295.8
WLTP - Pure Electric Range (miles) - Comb - TEH	276.5
WLTP - Pure Electric Range (miles) - Comb - TEL	302

Emissions - ICE

CO2 (g/km)	0

Engine and Drive Train

CC	1
Gears	1 SPEED
Transmission	AUTO

Fuel Consumption - ICE

EC Directive 1999/100/EC Applies	False

General

Alternative Fuel Qualifying	True
Badge Engine CC	0
Badge Power	238
Coin Description	175kW Recharge
Coin Series	Ultimate
Generation Mark	1
Insurance Group 1 - 50 Effective January 07	38E
Man Corrosion Perforation Guarantee - Years	12
Manufacturers Paintwork Guarantee - Years	3
NCAP Adult Occupant Protection %	92
NCAP Child Occupant Protection %	89
NCAP Overall Rating - Effective February 09	5
NCAP Pedestrian Protection %	70
NCAP Safety Assist %	89
Safety Concerns	False
Service Interval Frequency - Months	24
Service Interval Mileage	18000
Special Edition	False
Special Order	False
Standard manufacturers warranty - Mileage	60000
Standard manufacturers warranty - Years	3
Vehicle Homologation Class	M1

Performance

0 to 62 mph (secs)	7.3
Engine Power - BHP	238
Engine Power - KW	175
Engine Power - PS	True
Engine Torque - LBS.FT	310
Engine Torque - MKG	42.8
Engine Torque - NM	420
Top Speed	112

Test Cycles

Emissions Test Cycle	WLTP
RDE Certification Level	N/A

Tyres

Alloys	True
Space Saver	False
Tyre Size Front	235/45 R20
Tyre Size Rear	255/40 R20
Tyre Size Spare	TYRE REPAIR KIT
Wheel Style	5 SPOKE
Wheel Type	20" ALLOY

Vehicle Dimensions

Height	1596
Length	4440
Wheelbase	2702
Width	1910
Width (including mirrors)	2034

Weight and Capacities

Gross Vehicle Weight	2460
Luggage Capacity (Seats Down)	1205
Luggage Capacity (Seats Up)	413
Max. Loading Weight	483
Max. Roof Load	75
Max. Towing Weight - Braked	1500
Max. Towing Weight - Unbraked	750
Minimum Kerbweight	1977
No. of Seats	5
Turning Circle - Kerb to Kerb	11.4
